HBM HP200 Cone Crusher
• Equipped with manganese steel crushing members, hydraulic bowl clamping and adjustment, hydraulic clearing of crusher chamber, automatic tramp iron release, bronze bearings, package lubrication system (consisting of independent pump, oil pressure switch, oil temperature switch, oil tank with strainer, oil level gauge and two thermometers, oil heater and oil filter), oil cooler (air¨Cradiator type), tools, and 200 HP, 1.15 service factor, 1800 RPM, 460 volt, 3¨Cphase, 60 cycle, TEFC crusher drive motor.

Metso/Nordberg 6'x16' Triple Deck Vibrating Horizontal Heavy Duty Screen Model FS303

Equipped with triple shaft exciter, field adjustable stroke, splash oil lubricated, back plates, feed box with AR steel replaceable discharge lips, side tension plates, screen walkway, under screen hopper made from mild steel with AR liners, screen chute made from mild steel with AR liners, V¨Cbelts, and V¨Cbelt guard, motor sheave, 50 HP, 1800 RPM, TEFC drive motor.
60" Under Screen Product Conveyor
• Equipped with 5" CEMA 'C' idlers, vulcanized head pulley, wing type foot pulley, nip guards, 2 ply belting, heavy duty frame, Class I torque arm reducer drive, rubber disc return idlers, V¨CBelt and V¨CBelt guard, motor sheave, 10 HP, 1800 RPM, TEFC drive motor,Argonics Eraser Belt Scraper.
36" Rear Discharge Conveyor
• Equipped with 5" CEMA 'C' idlers, vulcanized head pulley, wing type foot pulley, nip guards, skirt plates, 3 ply belting, heavy duty frame, class I torque arm reducer drive, return belt plow, rubber disc return idlers, V¨CBelts and V¨CBelt guard, motor sheave, 10 HP, 1800 RPM, TEFC drive motor.
36" Recirculating Conveyor
Equipped with 5" CEMA 'C' idlers, vulcanized head pulley, wing type foot pulley, nip guards, skirt plates, 3 ply belting, heavy duty frame, class I torque arm reducer drive, return belt plow, rubber disc return idlers, V¨CBelts and V¨CBelt guard, motor sheave, 5 HP, 1800 RPM, TEFC drive motor.
36" Screen Feed Conveyor
• Equipped with 5" CEMA 'C' idlers, vulcanized head pulley, wing type foot pulley, nip guards, skirt plates, receiving hopper with AR liners, 3 ply belting, heavy duty frame, Class I torque arm reducer drive, rubber disc return idlers, V¨CBelts and V¨CBelt guard, motor sheave, 20 HP, 1800 RPM, TEFC drive motor.

Hydraulic Elevator Assembly
• For screen feed conveyor

18" x 10' Side Discharge Product Conveyor
• Equipped with 5" CEMA ¡®C' idlers, Rulmeca motorized 5.5 HP drive pulley, wing type foot pulley, skirt plates, 2 ply belting

Heavy Duty Chassis with Triple Axle
• Equipped for semi trailer towing with 11:R22.5 load range 'G' tires on Budd type wheels, air controlled brakes, fifth wheel kingpin, under crusher discharge hopper with AR liner strips, crusher feed basket, horizontal screen support frame, conveyor supports, travel lights, reflectors, mud flaps, crusher motor mounting parts and V¨CBelt drive guards

Included Options:
• Additional lube oil heater¨C less wiring and controls. One oil heater is supplied as standard equipment, customers may order an additional heater as a spare, for application in extreme cold or to operate from a secondary power source. The oil heater is 4 kw, 460 volt, 3 phase.
• Adjustable king pin support. Adjustable tubular supports reduce the amount of blocking required in the kingpin area during plant operation, which simplifies set up and tear down. The kingpin supports are lifted and pinned for towing to clear the semi¨Ctractor.

• Power hydraulic raise and lower ¨C Six tube in tube style heavy duty run¨Con jacklegs, with 6" diameter x 18" stroke cylinders to lift the plant into the operating position. Each cylinder is independently controlled from a hydraulic valve for precise control and ease of leveling. The hydraulic system is powered an 11 HP Honda gasoline engine with electric start and backup recoil start.

• Electric Starters, Wiring and Controls ¨C 6' x 6' x 20" electrical enclosure with structural support to set on grade during plant operation. The enclosure is connected to the plant with 15' electrical cable. The enclosure has a main inlet line surge arrestor, warning horn, lifting eyes and main circuit breaker with door interlocked disconnect linkage. All on¨Cplant equipment is controlled by NEMA rated starters. Crusher motor is controlled by a digital solid state reduce voltage starter (soft¨Cstart) which may be bypassed for across¨Cthe¨Cline starting, an internal hour meter and an external amp meter. All push buttons, pilot lights and E¨Cstop switches are heavy duty, 30mm, oil and dust tight devices. Includes an hour meter located inside the enclosure and a door mounted amp meter for crusher amperage. Furnished with an external 15 amp, 120 volt, GFI outlet. Cable mounting
• Chassis identification ¨C English
• Ladder Holder
